Micro dynamique SHURE SM 57

Type

Dynamic

Frequency Response

40 to 15,000 Hz

 View Larger

Polar Pattern

Unidirectional (cardioid), rotationally symmetrical about microphone axis, uniform with frequency.

Sensitivity (at 1,000 Hz)

Open Circuit Voltage: -56.0 dBV/Pa* (1.6 mV)

*(1 Pa = 94 dB SPL)

Impedance

Rated impedance is 150 ohms (310 ohms actual) for connection to microphone inputs rated low impedance

Polarity

Positive pressure on diaphragm produces positive voltage on pin 2 with respect to pin 3

Connector

Three-pin professional audio connector (male XLR type)

Case

Dark gray, enamel-painted, die-cast steel with a polycarbonate grille and a stainless steel screen

Dimensions

See User Guide

Net Weight (without cable)

284 grams (10 oz)
